General |
|
| Light modes | off, on or dim |
|---|---|
| Amplifier Power (RMS) | 1000 W or 2000 W RMS short-term (depending on model) |
| Power modes | off, on or automatic (signal-sensing) |
| Warranty | 3 years |
Signal Processing |
|
| Unbalanced inputs | Stereo or mono (two RCA jacks) |
|---|---|
| Balanced inputs | Stereo or mono (two female XLR jacks) |
| Input grounding | Isolated or grounded |
| Input modes | Master or slave |
| Level control | Reference (fixed gain) or Variable, from full mute to +15 dB over reference gain |
| Filter mode(s) | Low-pass |
| Filter slope(s) | 12/24 dB/octave |
| Filter frequency range | 30 Hz-130.1 Hz |
| Filter defeat function | |
| Polarity | 0 or 180º |
| Phase | Variable, 0-270º, referenced to 80 Hz |
| Output to slave | Balanced (one male XLR jack) |
| Calibration mode | Digital Automatic Room Optimization (D.A.R.O.), includes laboratory-grade microphone |
Amplifier Specifications |
|
| Width (W) | 17.4″ (442 mm) |
|---|---|
| Height (H) | 3.5″ (89 mm) |
| Depth (D) | 17.9″ (455 mm) |
| Net weight (each) | 13.5″: 35 lbs (15.9 kg) Dual 13.5″: 43 lbs (19.5 kg) |
