General
1.9 lbs (0.9 kg)
Electrical Features |
|
| Power input | 10-32 V |
|---|---|
| Power usage | 21 W typical, 58 W max |
| Fuse | 7.5 A |
Sonar Features |
|
| Frequency | 530 – 1,100 kHz |
|---|---|
| Transmit power | 500 W |
| Maximum depth | Down and Forward: 200’ (61.0 m) |
| Sonar Type | Live |
| Target Separation @100′ | 22″ |
Connections |
|
| Marine Network Ports |
1 (small connector) |
|---|---|
Sonar Modes |
|
| LiveVü Down | |
|---|---|
| LiveVü Forward | |
| Perspective mode | |
| Traditional sonar source | |
