General |
|
| Sizes | 2.75″/3.5″ |
|---|---|
| Continuous power handling (RMS) | 2.75″: 30 W 3.5″: 35 W |
| Sensitivity (SPL @ 1 W/1 m) | 2.75″: 82 dB 3.5″: 86 dB |
| Frequency response (+/- 3 dB) | 450 Hz-20 KHz ± 3 dB |
| Nominal impedance | 4 Ω |
| Recommended amplifier power (RMS) | 2.75″: 10-40 W/Channel 3.5″: 10-50 W/Channel |
| Cone material | Fiber-reinforced pulp |
| Grille(s) included | |
| Warranty | 1 year |
Connections |
|
| Speaker connections | Spade connectors |
|---|---|
Mounting Dimensions |
|
| Frame outer diameter | 2.75″: 2.85″ (72 mm) 3.5″: 3.46″ (88 mm) |
|---|---|
| Mounting depth clearance | 2.75″: 1.39″ (35 mm) 3.5″: 1.59″ (40 mm) |
| Frontal grille protrusion | 0.26″ (7 mm) |
| Mounting hole | 2.75″: 2.48″ (63 mm) 3.5″: 3.12″ (80 mm) |
| Motor outer diameter | 1.29″ (33 mm) |
