General |
|
| Sizes | 4″/5 x 7″/5.25″/6 x 9″ |
|---|---|
| Continuous power handling (RMS) | 4″: 35 W 5 x 7″/5.25″/6.5″: 50 W 6 x 9″: 60 W |
| Sensitivity (SPL @ 1 W/1 m) | 4″: 84.5 dB 5 x 7″: 90.5 dB 5.25″: 89 dB 6 x 9″ (2-way): 91.5 dB 6 x 9″ (3-way)/6.5″: 90.5 dB |
| Frequency response (+/- 3 dB) | 4″: 64 Hz-24 KHz 5 x 7″: 40 Hz-24 KHz 5.25″: 54 Hz-24 KHz 6 x 9″ (2-way): 39 Hz-22 KHz 6 x 9″ (3-way): 36 Hz-24 KHz 6.5″: 48 Hz-24 KHz |
| Nominal impedance | 4 Ω |
| Recommended amplifier power (RMS) | 4″: 10-50 W/Channel 5 x 7″/5.25″/6.5″: 10-75 W/Channel 6 x 9″: 10-100 W/Channel |
| Voice coil diameter | 4″/5 x 7″/5.25″/6.5″: 1″ (25 mm) 6 x 9″: 1.2″ (30 mm) |
| Cone material | Mineral-filled polypropylene |
| Tweeter type | Aluminum Dome |
| Tweeter size | 4″/5 x 7″/5.25″/6.5″: 0.75″ (19 mm) 6 x 9″ (2-way): 1″ (25 mm) 6 x 9″ (3-way): 1″ (25 mm) and 0.75″ (19 mm) |
| Warranty | 1 year |
Connections |
|
| Speaker connections | Spade connectors |
|---|---|
Mounting Dimensions |
|
| Frame outer diameter | 4″: 4.03″ (102 mm) 5 x 7″: 5.50 x 7.63″ (140 x 194 mm) 5.25″: 5.83″ (132 mm) 6 x 9″ 6.38 x 9.33″ (162 x 237 mm) 6.5″: 6.25″ (159 mm) |
|---|---|
| Mounting depth clearance | 4″: 1.81″ (46 mm) 5 x 7″: 2.46″ (63 mm) 5.25″: 2.42″ (62 mm) 6 x 9″ (2-way): 2.75″ (70 mm) 6 x 9″ (3-way): 3.09″ (79 mm) 6.5″: 2.07″ (53 mm) |
| Mounting hole | 4″: 3.70″ (94 mm) 5.25″: 4.70 in (119 mm) 6.5″: 5.02″ (128 mm) |
| Motor outer diameter | 4″: 2.33″ (59 mm) 5 x 7″/5.25″: 2.76″ (70 mm) 6 x 9″ (2-way): 3.54″ (90 mm) 6 x 9″ (3-way): 3.94″ (100 mm) 6.5″: 3.15″ (80 mm) |
| Frontal coaxial tweeter protrusion (frontal grille protrusion measured from mounting surface) | 4″: 0.61″ (16 mm) 5 x 7″: 0.46″ (12 mm) 5.25″: 0.54″ (14 mm) 6 x 9″ (2-way): 0.41″ (10 mm) 6 x 9″ (3-way)/6.5″: 0.72″ (18 mm) |
