Physical & Performance
- Physical Dimensions (unit, rack, connectors): 1.65” x 6.30” x 9.9” (42 x 160 x 224 mm)
- Weight (unit, rack, connectors): 2.8/2.9 lbs (1.27/1.32 kgs)
- Voltage range: 14/28 VDC (18/20 W Max)
- Transmit power: 200 W minimum
- Tempertaure: -45°C to +70°C
- Operating altitude: To 55,000 ft (16,800 m)
- Cooling input: Not required
- Environmental Compliance (TSO Approved): DO-160G
- Software compliance (TSO Approved): DO-178 Levels B, C, D, E
- Hardware compliance (TSO Approved): DO-254 Level C
- TSO compliance (Approved): TSO-C88b (w/opt. alt. encoder); TSO-C112e (Class 1, Level 2els); TSO-C154c (Class A1S); TSO-C157a (Class 1); TSO-C166b (Class A1S); TSO-C195a (Class C1,C2,C3,C4)
- Mount type: Remote
- Transponder type: Mode A/C, S and ES
- Squawk code selection: Remote entry
- Traffic Information Services (TIS) alerts compatible: Yes
Transponder Features
Solid state transmitter (more efficient, longer life): Yes
Aural alerts: Yes
Automtatic ALT/GND mode: Yes
U.S. subscription-free weather and traffic: Yes
1090 MHz ADS-B Out: Yes
Dual-link 1090 MHz and 978 MHz UAT ADS-B In: Yes
TAS/TCAS traffic integration with ADS-B In: Yes
