General
| Width | 3.25″>” (82.6 mm) |
| Height | 3.25″>” (82.6 mm) |
| Depth | 6.44″>” (163.6 mm) |
| Depth with connector | 7.40″>” (188.0 mm) |
| Unit weight | 1.9 lbs (0.86 kg) to 2.4 lbs (1.1 kg) |
| Active display size | 2.69” diameter |
| Display resolution | 480 x 433 pixels |
| Operating voltage | 14/28 VDC |
| Operating temperature range | -20°C to +55°C< |
| Altitude range | -1,500 ft to 55,000 ft |
| Wi-Fi class | 802.11b/g/n |
Rotary Aircraft Models Currently FAA Approved for GI 275 Installation
| Aircraft | Model(s) |
| Airbus AS350 | BA, B2, B3 |
| Bell | 4071 |
| Robinson | R66 |
1Not approved in Bell 407 GXi variants equipped and approved for IFR operations.
Last Updated: 6/6/2023
