General |
|
| Physical dimensions (Diameter x Depth) | 12″ Sports: 14.02″ x 10″ (356 x 254 mm) 10″ Classic: 10.83″ x 6.38″ (275 x 162 mm) 10″ Sports: 10.83″ x 6.77″ (275 x 172 mm) |
|---|---|
| Water and dust rating | IP65 |
| Speaker size | 1,400 Watt Sports Chrome/White: 12″ 600 Watt Classic and Sports Chrome/White: 10″ |
| Peak power (Watts) | 12″: 1,400 W 10″: 600 W |
| RMS power (Watts) | 12″: 700 W 10″: 300 W |
| Sensitivity (1 W / 1 m) | 86 dB |
| Magnetic structure | 12″: 113 oz 10″: 68 oz |
| Frequency response | 12″: 20 Hz – 2 kHz 10″: 30 Hz – 2 kHz |
| Nominal impedance | 4 ohms |
| Recommended amplifier power (RMS) | 12″: 200 – 1000 W 10″: 50 – 600 W |
| LED lighting | Yes – CRGBW (sports-style only) |
| LED Supply Voltage | 10.8-16 VDC (sports-style only) |
| LED load current @ 14.4 VDC | 300 mA (sports-style only) |
| Operating temperature range | 32° to 122° F (0° to 50° C) |
| Voice coil diameter | 12″: 4″ 10″: 2″ |
| Cone material | Polypropylene cone with rubber surround |
| Compass-safe distance | 12″: 181″ (460 cm) 10″: 205″ (520 cm) |
| Warranty | 3 years |
Mounting Dimensions |
|
| Mounting diameter clearance | 12″: 12.05″ (306 mm) 10″: 8.78″ (223 mm) |
|---|---|
| Mounting depth clearance | 12″: 8.15″ (207 mm) 10″: 5.24″ (133 mm) |
Optimum Enclosure Recommendations |
|
| Sealed enclosure volume1 | 12″: 2.12 cubic ft (60 L) 10″: 0.6 cubic ft (17.2 L) |
|---|---|
| Ported (vented) enclosure volume2 | 12″: 8.83 cubic ft (250 L) 10″: 1.6 cubic ft (45 L) |
| Port diameter | 12″: 4″ (101.6 mm) 10″: 4.1″ (104 mm) |
| Port length | 12″: 5″ (127 mm) 10″: 10.43″ (265 mm) |
1Fully filled with absorption material
2Lined with absorption material
