General
1.23 lbs (556 g)
Networking |
|
| NMEA 2000Ā® LEN | see Additional |
|---|---|
| BluetoothĀ® wireless range | up to 30 ft |
| ANTĀ® wireless range | Up to 10 ft |
| Wireless frequencies/protocols | BLUETOOTHĀ®: 2.4 GHz @ +1.9 dBm nominal ANTĀ®: 2.4 GHz @ +1.9 dBm nominal |
Audio |
|
| Amplifier | Class-AB (4 ohm) |
|---|---|
Electrical Features |
|
| Power Input | 10.8 – 16 VDC |
|---|---|
| Compass-safe distance | 5.9″ (150 mm) |
Stereo Features |
|
| Peak power | 200 W |
|---|---|
| Rated power output (4 ohm) | 26 watts RMS x 4 @ 14.4 V input < 10% THD |
| Fusion-Linkā¢ control | yes (see Additional) |
| Multi-Zoneā¢ technology | 2 zones |
| BluetoothĀ® wireless technology | |
| ANTĀ® wireless technology | |
| SiriusXM-ready | see Additional |
| DAB+ ready | see Additional |
| Supports NRX wired remote | see Additional |
| Multi-language interface | Dutch, English, French, German, Italian, Spanish |
| Software updates | USB |
| Warranty | 1year |
Sources |
|
| Supported sources |
AM, FM, BLUETOOTH®, USB audio, iPhone®, iPod®, AUX x1, AOA MS-RA70NSX: SiriusXM-Ready (U.S. only, requires optional SiriusXM Connect vehicle tuner) MS-RA70 and MS-RA70N: DAB+ ready (available in Europe and Australia only) |
|---|---|
Connections |
|
| Auxiliary inputs (RCA) | 1 |
|---|---|
| NMEA 2000Ā® ports | 1 (MS-RA70N and MS-RA70NSX only) |
| USB 2.0 ports | 1 |
| SiriusXM ports | 1 (MS-RA70NSX only) |
| AM/FM ports (Motorola antenna connector) | 1 |
| Speaker connections | 4 (2 zone amplified) |
| RCA pre-out (left, right and subwoofer) | 2 zones (requires external amplification) |
| Line out | 2 (L + R per zone, requires external amplification) |
| Subwoofer out | Zone 1 (mono output, requires external amplification) |
Additional |
|
| Additional |
NMEA 2000® LEN: 1 (50 mA), MS-RA70N and MS-RA70NSX only Fusion-Link™ control: MS-RA70: smart device and watch; MS-RA70 and MS-RA70NSX: MFD, smart device and watch SiriusXM-Ready: MS-RA70NSX only DAB+ Ready: MS-RA70 and MS-RA70N only Supports NRX wired remote: MS-RA70N and MS-RA70NSX only |
|---|---|
